Amana AMVC800805DN Gas Furnace — 80,000 BTU, 80% AFUE, Variable-Speed ECM Motor, Two-Stage Operation, and Convertible Upflow/Downflow Configuration

Description

AMVC800805DN

1. Heavy-duty stainless-steel tubular heat exchanger
2. Efficient and quiet variable-speed Blower
3. Integrated communicating Comfort Bridge technology
4. Commissioning and diagnostics via on board Bluetooth with the Cool Cloud phone and tablet application
5. Two-Stage gas valve
1. Higher reliability and quality
2. Airflow system gently ramps up or down according to heating or cooling demand and provides better comfort
3. Capable of using non communicating single-stage thermostats
4. Operates on single-stage thermostats

• Equipment
• Amana 80% AFUE Gas Furnace Variable Speed ECM, Two Stage Convertible, Upflow/Horizontal, 80,000 BTUH/H, Non NOx Rated
• Indoor
• Comfort Bridge-Compatible Two-Stage, Variable-Speed ECM Gas Furnace 80% AFUE

SPECIFICIATIONS:

• Brand Amana
• Product Family AMVC80
• Family Description Comfort Bridge-Compatible Two-Stage, Variable-Speed ECM Gas Furnace 80% AFUE
• Unit Type Indoor
• Product Class – (PIM) Gas Furnace
• Model Efficiency 0.80
• Product Benefits
• 1. Higher reliability and quality
  2. Airflow system gently ramps up or down according to heating or cooling demand and provides better comfort
  3. Capable of using non communicating single-stage thermostats
  4. Operates on single-stage thermostats
• Product Features Standard
• 1. Heavy-duty stainless-steel tubular heat exchanger
  2. Efficient and quiet variable-speed Blower
  3. Integrated communicating Comfort Bridge technology
  4. Commissioning and diagnostics via on board Bluetooth with the Cool Cloud phone and tablet application
  5. Two-Stage gas valve
• Cabinet Features Fully insulated heavy-gauge steel cabinet with durable baked-enamel finish multi-position installation: AMVC 80: up flow horizontal left or rightACVC80: downflow horizontal left or right Removable bottom for side- or bottom-return applications Convenient left or right connection for gas/electric service Cabinet air leakage ≤ 2% Coil and furnace fit flush for most installations
• NOx Burner Type Non-NOx Rated
• AFUE80
• Blower Motor RPM 1200
• Air Flow Rate (High) – Heating 1760
• Air Flow Rate (Low) – Heating 1175
• High-Fire Input Capacity 80000
• High-Fire Output Capacity 64,000
• Power Voltage 115
• Min. Circuit Amps 10.6
• Power Phase 1
• Power Frequency 60
• Dimensions – (Unit Depth) 28
• Dimensions – (Unit Width) 24-1/2
• Dimensions – (Unit Height) 33.3
• Weight – (Unit) 129
• Motor Speed Type Variable Speed ECM
• Proposition 65:  Yes
• Vendor AMANA CO LP
