Motone Multifunction Rear Extended Wiring Harness – Plug-and-Play for 2016+ Triumph Classic Models

Description

This is the Extended (+120cm) XL version of the loom – useful if you are mounting the Tail light on the shock or somewhere further out – we designed this to go with our Sidewinder side mount number plate/license plate kits and it comes as part of the Kit

Now includes Triple Plugs so it can work concurrently with 3in1 lights as well as tail lights

Plug and play wiring loom for all the Liquid Cooled Triumph Twins meaning all the twins 2016 and up

Euro 4 and Euro 5 : Street Twin, Street Cup, T100, T120, Thruxton R, Thruxton S, Street Scrambler,

Euro 4 Speed Twin (2019-2020)

Does not fit Bobber and Speedmaster (See DDM016) and Euro 5  Speed Twin (2022 and on) – (DDM017)

Our Adapter comes both colour and letter coded with each function banded together and labelled for easy use.

NOTE : MOTONE LOOM INCLUDES DIODE INLINE TO PREVENT ECU WARNING LIGHT ERROR ON NON-TRIUMPH LIGHTS

It also utilises all 6 of the stock loom plugs giving you an extra live connector to run any auxiliary devices

T : Tail light –

RED – BRAKE Light

YELLOW – RUNNING Light

BLACK – Earth

L : Left Indicator/Turn Signal

BROWN – LHS Signal

BLACK – Earth

R : Right Indicator/Turn Signal

ORANGE – RHS Signal

BLACK – Earth

A : Auxiliary Live

GREEN – AUX

BLACK – Earth

Note : 6-Way loom connector hermetically sealed to prevent water ingress
