Pacific Coast 10 AWG Black Photovoltaic Wire — 100-Foot Roll with MC4 Male-to-Female Connectors

Description

The Pacific Coast Wires PCWCBLK100MC4MF is a 100‑foot roll of 10 AWG copper PV wire with factory‑installed MC4 male and female connectors. Designed for modern solar installations, this cable is UL‑listed, sunlight‑resistant, and rated for 600V/1000V/1500V PV systems depending on installation type.

Built for durability and flexibility, it’s ideal for module home‑runs, string extensions, and array wiring in residential and commercial PV systems.

⭐ Key Features

• 10 AWG stranded copper PV wire

• 100 ft continuous length

• Pre‑terminated with MC4 male + MC4 female connectors

• UV‑resistant, weather‑resistant, and direct‑burial rated

• Suitable for 600V / 1000V / 1500V PV system applications

• Flexible insulation for easy routing

• Meets UL 4703 PV wire standards

📐 Specifications

• Model / SKU: PCWCBLK100MC4MF

• Gauge: 10 AWG

• Conductor: Stranded copper

• Insulation: XLPE (PV‑rated)

• Color: Black

• Length: 100 ft

• Connectors: MC4 male + MC4 female

• Voltage Rating: Up to 1500V (PV systems)

• Certifications: UL 4703, RoHS

🔧 Common Uses

• Solar module home‑run wiring

• String extensions

• Inverter/combiner box connections

• Off‑grid and grid‑tie PV systems

• RV, marine, and mobile solar setups
